08B Side Bow Roller Chain Assembly

Description

08B side bow roller chain has a 12.7mm pitch and is manufactured in accordance with ISO British Standards. Though it is a side bow chain, it still runs on standard 08B metric sprockets. This 08B side bow chain offers exceptional performance and working life due to using high-quality heat-treated components and being shipped with a premium lubricant already applied to the chain. Typically this chain will come in 10ft boxes including a connecting link but longer-length custom lengths can be made upon request. For more information or to get a quote please contact us and we will be happy to assist you.

08B Side Bow Chain Dimensions

• Pitch (P): 12.7mm
• Width Between Inner Plates (W): 7.75mm
• Roller Diameter (R): 8.51mm
• Pin Diameter (D): 4.45mm
• Inner Link Overall Width (B): 11.30mm
• Plate Height (H): 11.8mm
• Pin Length (F): 17.1mm
• Connecting Link Width (O): 18.3mm
• Minimum Flex Radius (R): 315mm
• Weight: 0.7 kG/ M
