10Btb25H Taper-Bushed Sprocket – #10B Pitch Chain Fit

Description

This 10BTB25H sprocket is a metric taper bushed style roller chain sprocket manufactured under ISO and British Standard 228. and is made to accept a 2012 taper bushing. Our 10BTB25H sprockets are made with reliability and performance in mind, so we use high-quality carbon steel (CS) and have the sprocket precision cut to ensure maximum performance and wear life. We also offer upgrades on our 10BTB25H sprockets such as black-oxide coatings and heat-treated hardened teeth, hardened teeth increases the durability and wear life of the sprocket while a black oxide coating will create an “anti-rust” coating on the sprocket. Besides the 25 tooth sprocket, we also stock a high-quality 10B roller chain, 2012 bushings, and a wide array of roller chain accessories. For more information or to get a quote on taper bushed 10BTB25H sprockets, please contact us and one of our sales team members will be happy to assist you.

10BTB25H Sprocket Dimensions

• Sprocket Size: 10BTB25H
• Tooth Count: 25
• Pitch Diameter: 126.66mm
• Bushing Size: 2012
• Maximum Bushing Bore: 50.80mm
• Length Thru Bore (L): 31.75mm
• Hub Diameter (C): 90.47mm
• Sprocket Weight: 1.09 kG
• Bushing Weight: 0.77 kG
