Description
CFL-10T rod end is a commercial-grade left-hand rod end constructed of two pieces; it is PTFE lined, making it maintenance-free. The two-piece metal-on-metal construction provides the most economical design for a broad range of light to heavy-duty applications. Our CFL10T rod end bearing features 52100 hard chrome plated balls encased within a carbon steel zinc plated housing. CFL-10T rod ends are in applications such as; construction equipment, agricultural equipment, plant machinery, and more. We do not supply any rod ends, including CFL-10T rod ends, for automotive on or off-highway vehicles! Additionally, our CFL-10T rod ends interchange with other brands that produce industrial rod ends. For more information or to get the pricing and availability on our CFL10T rod ends, contact our customer support team, and we will be happy to assist you.
CFL10T Rod End Dimensions
- Part #: CFL-10T
- Configuration: Left-Hand
- Dimension (B): 0.6250″ +0.0025/ -0.0005
- Dimension (D): 1.500″ +0.010/ -0.010
- Dimension (W): 0.750″ +0.005/ -0.005
- Dimension (T): 0.484″
- Ball Diameter: 1.125″
- Dimension (A): 2.500″ +0.015/ -0.015
- Thread (N): 5/8-18 UNF-2B
- Dimension (C): 1.375″ +0.062/ -0.031
- Dimension (E): 1.000″ +0.010/ -0.010
- Dimension (F): 0.875″ +0.010/ -0.010
- Angle (a): 26°
- Ultimate Static Radial Load: 9,800 LBS
- Weight: 0.43 LBS
