Description
HCFS209-28 bearing is a 1-3/4″ bore four-bolt normal-duty flange bearing that utilizes an eccentric locking device to secure to a 1-3/4″ shaft. HCFS209-28 flange bearings are designed for circumstances where the bearing is mounted to a surface perpendicular to the shaft axis and poses great stability and rigidity due to the four mounting positions. Our superior HCFS209-28 bearing with a 1-3/4″ bore is equipped with a premium C3 precision insert bearing housed within a high-strength solid-base cast-iron housing. Additionally, our HCFS209-28 bearing has added features that improve the overall life and performance of the unit, such as; a steel retainer, wide inner-ring, anti-rotation device, and relubricating capabilities. HCFS209-28 bearings are commonly used in applications such as; construction equipment, agricultural equipment, forestry, aggregate, conveyor systems, and many more. Our HCFS209-28 bearing is dimensionally made to industry standards, meaning it interchanges with just about any brand out there. Contact our customer support team for further information or to get a quote on our HCFS209-28 bearings, and we will be happy to assist you!
HCFS209-28 Bearing Dimensions
- Part #: HCFS 209-28
- Shaft Diameter (d): 1-3/4″
- Dimension (A): 5.31″
- Dimension (E): 4.125″
- Dimension (I): 0.94″
- Dimension (G): 0.71″
- Dimension (L): 1.57″
- Dimension (S): 0.63″
- Dimension (Z): 2.31″
- Dimension (Bi): 2.217″
- Dimension (N): 0.843″
- Dimension (M): 0.843″
- Bolt Used: 1/2
- Dynamic Load Rating (LBS): 7,160
- Static Load Rating (LBS): 4,676
- Bearing Insert: HC 209-28
- Housing Number: FS 209
- Weight (LBS): 5.3
