Description
HCTB210 bearing is a 50mm bore tapped-base normal-duty mounted bearing unit that utilizes an eccentric locking collar for securing onto a 50mm shaft. HCTB210 pillow block bearings have a unique housing designed for narrow applications with radial loads acting in the direction of the support surface. Our superior HCTB210 bearing with a 50mm bore is equipped with a premium C3 precision insert bearing housed within a high-strength solid-base cast-iron housing. Additionally, our HCTB210 bearing has added features that improve the overall life and performance of the unit, such as; a steel retainer, wide inner-ring, anti-rotation device, and relubricating capabilities. Tapped base HCTB210 pillow block bearings are commonly used in applications such as; construction equipment, agricultural equipment, forestry, aggregate, conveyor systems, and many more. Our HCTB210 bearings are manufactured to industry standard dimensions; they also interchange with just about any brand out there. Contact our customer support team for further information or to get a quote on our HCTB210 bearings, and we will be happy to assist you!
HCTB210 Bearing Dimensions
- Part #: HCTB 210
- Shaft Diameter (d): 50mm
- Dimension (H): 57.2mm
- Dimension (A): 140.0mm
- Dimension (E): 101.6mm
- Dimension (B): 51.0mm
- Dimension (R): 22.0mm
- Dimension (G): 14.0mm
- Dimension (W): 117.0mm
- Dimension (Bi): 62.7mm
- Dimension (N): 24.6mm
- Dimension (M): 24.6mm
- Bolt Used: 5/8-11
- Dynamic Load Rating (kN): 35.00
- Static Load Rating (kN): 23.71
- Bearing Insert: HC 210
- Housing Number: TB 210
- Weight (kg): 3.4
