Description
M1.5B23 spur gear is a module 1.5, 23-tooth B hub type metric gear that is 37.5mm in diameter. Our M1.5B23 gear is manufactured using high-strength C1045 steel which is the optimal material for spur gears, it is manufactured to the standard metric dimensions so it interchanges with other brands, and can be supplied as a plain stock bore or finished out to a specific bore size upon request. We also supply metric gear rack for M1.5B23 gears, and high-grade gear oil to increase performance and longevity of the gear. For additional information or to get a quote on M1.5B23 metric spur gears please contact us as (407) 347-3519 or email sales@usarollerchain.com and we will be happy to assist you.
M1.5B23 Gear Dimensions
- Gear Size: M1.5B23
- Tooth Count: 23
- Dimension (De): 37.5mm
- Dimension (Dp): 34.5mm
- Dimension (d): 25mm
- Dimension (D): 10mm
- Max Torque (Ncm): 361
- Weight: 0.16 Kg
