Description
M1B12 spur gear is a module 1, 12-tooth B hub type metric gear that is 14mm in diameter. Our M1B12 gear is manufactured using high-strength C1045 steel which is the optimal material for spur gears, it is manufactured to the standard metric dimensions so it interchanges with other brands, and can be supplied as a plain stock bore or finished out to a specific bore size upon request. We also supply metric gear rack for M1B12 gears, and high-grade gear oil to increase performance and longevity of the gear. For additional information or to get a quote on M1B12 metric spur gears please contact us as (407) 347-3519 or email sales@usarollerchain.com and we will be happy to assist you.
M1B12 Gear Dimensions
- Gear Size: M1B12
- Tooth Count: 12
- Dimension (De): 14mm
- Dimension (Dp): 12mm
- Dimension (d): 9mm
- Dimension (D): 5mm
- Max Torque (Ncm): 35
- Weight: 0.01 Kg
