Description
The Milescraft PocketJig400 Pocket Hole Jig Kit (#1327) is a heavy-duty woodworking solution designed for precise, repeatable pocket hole joinery. Featuring an all-metal construction and adjustable drill guides, it delivers enhanced rigidity and accuracy for professional-grade results in furniture, cabinetry, and structural woodworking.
Key Benefits
- All-metal construction increases rigidity for precise and consistent drilling
- Adjustable dual drill guides allow flexible spacing and board thickness compatibility
- Integrated storage and included accessories support efficient workflow
Product Overview
The Milescraft PocketJig400 is engineered for durability and versatility in demanding woodworking applications. Its aluminum body reduces flex during operation, while hardened steel drill guides ensure accurate hole alignment. The adjustable bushing blocks allow drilling on materials from 1/2″ to 1-1/2″ thick, with spacing flexibility from 3/4″ to 3″. The steel toggle clamp with micro-adjustment provides secure and consistent clamping pressure, improving precision across different board thicknesses. Designed for both bench-top and portable use, the removable L-base allows flexibility for on-site repairs and mobile projects. A built-in storage drawer keeps accessories organized and includes markings for quick depth setting adjustments.
Ideal Applications
- Cabinet making and furniture assembly
- Frame construction and structural joinery
- Professional woodworking and workshop production
Technical Specifications
| Brand | Milescraft |
| Model | 1327 (PocketJig400 Kit) |
| Product Type | Pocket Hole Jig Kit |
| Main Body Material | Aluminum |
| Drill Guide Material | Hardened Steel |
| Drill Guide Size | 3/8″ |
| Board Thickness Capacity | 1/2″ to 1-1/2″ |
| Bushing Spacing | 3/4″ to 3″ |
| Clamping System | Steel toggle clamp with micro-adjustment |
What’s Included
- Main Jig Body with Toggle Clamp
- Removable L-shaped Clamping Wall
- 2 Solid Steel Drill Guides
- 3/8″ Pocket Hole Bit
- 6″ T20 Magnetic Driver
- 3/8″ Split-Ring Depth Stop
- 10x 1″ Coarse Pocket Screws
- 10x 1.25″ Coarse Pocket Screws
- 10x 1.25″ Fine Pocket Screws
- 10x 1.5″ Coarse Pocket Screws
- 10x 2″ Coarse Pocket Screws
- 10x 2.5″ Coarse Pocket Screws
- 10x 3/8″ Pocket Plugs
- 3mm Hex Key
Learn more about our Warranty Policy or contact us for professional assistance.
