S-5B Split-Hub Sprocket – Removable Hub Design

Description

The S-5B split hub is designed for easy weldment onto a split A-plate sprocket and is precision manufactured from high-strength steel. S-5B hubs have a bore range of 3-3/4″ to 5″ and are 9-1/4″ in diameter. They are pieced together with two high-strength sprocket head-cap bolts. For more information or to get a quote on S-5B split hubs please contact us and we will be happy to assist you.

S-5B Hub Dimensions

• Hub Size: S-5B
• Bore Range: 3.75″ – 6.00″
• Hub Outside Diameter: 9.250″
• Bolt Size: 1″ X 6″
• Weight: 27.7 LBS

Note:

For B-hub configuration use one split hub with A-plate sprocket.

For C-hub configuration use two split hubs with A-plate sprocket.
