Triple E10B24 Sprocket – Standard Stock Bore Configuration

Description

This E10B24 sprocket with a stock bore is a metric roller chain sprocket manufactured under ISO and British Standard 228/11. Our E10B24 sprockets are made with reliability and performance in mind, so we use high-quality carbon steel (CS) and have the sprocket precision cut to ensure maximum performance and wear life. Besides the stock bore we also can supply these sprockets with a specific plain or finished (has key-way and set screws) bore size. We also offer upgrades on our triple E10B24 sprockets such as black-oxide coatings and heat-treated hardened teeth, though we often have these specific sprockets with those features already added right off the shelf. Besides the 24 tooth sprocket, we also stock a high-quality 10B-3 roller chain and a wide array of roller chain accessories. For more information or to get a quote on E10B24 sprockets, please contact us and one of our sales team members will be happy to assist you.

E10B24 Sprocket Dimensions

• Sprocket Size: E10B24
• Tooth Count: 24
• Pitch Diameter: 121.62mm
• Stock Bore: 20mm
• Maximum Recommended Bore: 64mm
• Hub Diameter (H): 100mm
• Length Thru Bore (L): 60mm
• Sprocket Weight: 4.00 kg
