Description
E50P16H Sprocket is a triple 16-tooth taper bushed style sprocket that utilizes a P2 bushing. Our triple E50P16H sprocket is dimensionally manufactured following ANSI Standards, which essentially means that it directly interchanges with other brands. More specifically to our sprocket, it is made utilizing high-quality mild steel and is made with high precision tolerances for optimal long-term performance. The sprocket also has heat-treated hardened teeth that further increases the working life and durability. Besides the sprocket, we also stock P2 bushings, 50-3 roller chain, v-belts, v-belt pulleys, electric motors, gear reducers, bearings, and much more! For more information or to get a quote please contact our customer service team and we will be happy to assist you.
E50P16H Sprocket Dimensions
- Sprocket Size: E50P16H
- Tooth Count: 16
- Bushing Used: P2
- Outside Diameter: 3.520″
- Pitch Diameter: 3.204″
- Sprocket Type: 22
- Maximum Bushing Bore: 1-3/4″
- Dimension (OL): 3-3/8″
- Dimension (L): 2-15/16″
- Dimension (C): 3/16″
- Dimension (H): 3″
- Dimension (P): 1-3/8″
- Dimension (T): 0.332″
- Sprocket Weight: 2.4 LBS
