Description
UEST212-39 bearing is a 2-7/16″ bore normal-duty take-up bearing that utilizes a Tru-Loc device to secure to a 2-7/16″ shaft. UEST212-39 take-up bearings are designed for take-up frames, which creates an assembly that maintains and adjusts tension for conveyor and drive systems. Our superior UEST212-39 bearing with a 2-7/16″ bore is equipped with a premium C3 precision insert bearing housed within a high-strength solid cast-iron housing. Additionally, our UEST212-39 bearing has added features that improve the overall life and performance of the unit, such as; a steel retainer, wide inner-ring, anti-rotation device, and relubricating capabilities. Our UEST212-39 bearing is dimensionally made to industry standards, meaning it interchanges with just about any brand out there. Contact our customer support team for further information or to get a quote on our UEST212-39 bearings, and we will be happy to assist you!
UEST212-39 Take-Up Bearing Dimensions
- Part #: UEST 212-39
- Shaft Diameter (d): 2-7/16″
- Dimension (O): 1.25″
- Dimension (G): 0.75″
- Dimension (P): 4.00″
- Dimension (Q): 2.50″
- Dimension (S): 1.38″
- Dimension (B): 4.00″
- Dimension (K): 1.06″
- Dimension (E): 5.13″
- Dimension (A): 5.75″
- Dimension (W): 7.63″
- Dimension (J): 2.50″
- Dimension (L): 1.65″
- Dimension (H): 4.69″
- Dimension (Bi): 2.6220″
- Dimension (N): 1.0000″
- Dimension (M): 1.5630″
- Dynamic Load Rating (LBS): 10,720
- Static Load Rating (LBS): 7,516
- Bearing Insert: UE 212-39
- Housing Number: ST 212
- Weight (LBS): 11.2
