Description
Style 115 flared trough end for 14″ screw conveyor with 3-7/16″ self-aligning ball bearing is designed with a top flange to support the cover and a bottom flange which serves as feet for the screw conveyor. Our flared trough ends are manufactured from high-quality heavy-gauge steel for superior strength and holding capacity over time. 115 flared trough ends are designed to specifically fit a flared trough. Typically, 115 trough ends are fitted with a self-aligning ball bearing but additional bearing types are available such as bronze, Arguto wood, nylon, bronze oilite, and it can be fitted with a Chevron or Hammond end thrust bearing as well. For more information or to get a quote on #115 flared trough end for 14″ screw conveyor with 3-7/16″ ball bearing contact us and our customer service team will be happy to assist you!
115 Flared Trough End For 14″ Conveyor With 3-7/16″ Bearing Dimensions
- Part #: 230-0564-115
- Diameter of Conveyor: 14″
- Bearing Bore: 2-7/16″
- Dimension (A): 28-3/8″
- Dimension (B): 3″
- Dimension (C): 2″
- Dimension (D): 11″
- Dimension (E): 10-7/8″
- Dimension (F): 1-5/8″
- Dimension (G): 2-7/8″
- Dimension (H): 5/8″
- Dimension (J): 13-1/2″
- Dimension (K): 5/16″
- Weight With Bearing: 96 LBS
