Csb208 Insert Bearing – 40Mm Bore, Eccentric Locking Design

Description

CSB208 bearing is a light-duty ball bearing insert made to C3 precision standards and utilizes set-screws to secure to a 40mm shaft. Our CSB208 insert bearing has several features: a wide inner-ring, steel retainer, anti-rotation device, and an inner ring and outer ring made from bearing grade steel to produce a high-quality and long-lasting bearing. Our CSB208 bearing is made to industry standards dimensionally for direct interchangeability with just about any brand. For additional information or to receive a quote on our CSB208 bearings, contact our customer service and, we will be happy to assist you!

CSB208 Bearing Dimensions

• Part #: CSB208
• Shaft Diameter (d): 40mm
• Setscrew Used: M8 x 1
• Dimension (D): 80.0mm
• Dimension (Bi): 34.0mm
• Dimension (Be): 18.0mm
• Dimension (N): 9.0mm
• Dimension (M): 25.0mm
• Dimension (G): 8.0mm
• Dimension (T): 6.0mm
• Dynamic Load Rating (kN): 29.51
• Static Load Rating (kN): 18.14
• Weight (kg): 0.6
